Technology Parameters
| Model | HTRS330 |
| Max. Rewinder Roller Diameter(mm) | Φ800 |
|
Max. Paper Width(mm) |
330 |
| Max. Speed(m/min) |
Air Shaft Dia(25-38): 100 Air Shaft Dia(40-76): 150 |
|
Rectifying Mode |
Ultrasonic |
| Paper Core Sizing | Hot Melt Adhesive |
| Paper Roll Sealing | Hot Melt Adhesive |
| Discharging | Auto |
| Air Pressure | 80Psi（5.5Ati） |
| Power | 380V(3 phase） |
| Overall Size(mm) | 2480x1480x2500 |
Function
Features
1、Adopt servo drive to make tension control more stable
2、Four-station rotary tower
3、Automatic paper core coating,sealing and discharging
4、Automatic core winding and cutting, and two modes of length and winding diameter can be realized
5、Shear cutting device
6、Equipped with this machine, it can be connected with various rotary printing machines for small volume automatic winding, or independently use to cut the large volume of finished materials by section and automatically rewind the small volume.
7、It is used for the production of finished products in small forms, such as label industry, clothing label,RFID material label, supermarket label
